• Meets or exceeds TIA/EIA-568-B.2-1 Category 6 Component Performance Specification.
• Tested for NEXT, PS-NEXT, FEXT, Return Loss, and Attenuation up to 350MHz.
• Includes Cable Ties, Cable Organizer and Mounting Hardware
The NEXION 12-PORT PATCH PANEL CAT 6 has 12 ports in the front which are hard-wired to 12 terminals at the back. The ports are numbered. The terminals at the back are colour-coded for easy termination of wires.
The cables from the different Work Stations in the network terminate at the back of the NEXION 12-PORT PATCH PANEL CAT 6. The termination is done on the Patch Panel terminals with a Punch-Down tool. The colour-coded terminals ease the cable termination. The terminated cables are already hard-wired to the different ports of the Patch Panel.
At the front of the NEXION 12-PORT PATCH PANEL CAT 6, the Patch Panel ports are “jumpered” to the network switch using NEXION patch cables (or “Fly-Cables” or “Fly-Leads”). A direct connection, swappable when necessary, has thus been made from the Work Station / Faceplate to the Network Switch. The Patch Panel facilitated this.
The advantage of using the NEXION Patch panel is that it allows manual monitoring, testing, switching, and other maintenance activities to be handled quickly. This is because the cables in the front that connect to the more permanent cables in the back are easily swappable allowing changes to be made quickly and easily when necessary. You do not have to re-run cables every time you want to maintain or swap locations.
